Description

Optional soft close
Quick door mounting
No guide rails in the floor
A wood cover panel is not needed

Specifications

  • Number of doors: 2.00
  • Soft closing mechanism: with clip-in door stopper
  • For door thickness: 16 – 19 mm
  • For door width: ≤1,000 mm
  • For door weight: ≤16 kg
  • Running position: Top
  • Number of rollers: 2.00
  • Height adjustment: -1 – 2 mm
  • Running gear guided by: Friction bearing
  • For door material: wood
  • Door width max.: 39 3/8"
  • For door thickness min.: 5/8" and 3/4"
  • Door weight max.: 35 lbs.
  • Height adjustment: +1/16-1/32"
  • Door height min.: 55 1/8"
  • Cabinet version: with thin cabinet top panels
  • Area of application: For thin cabinet top panels
  • For door height: ≤1,400 mm
  • Door stopper: Top clip-in door stopper, for sliding into single running track
  • Material/finish: Housing: PlasticRunning gear: PlasticGuide: PlasticRollers: PlasticAxis: Steel
Fulfill

Hafele HAWA Clipo 16 H MF Sliding Door Hardware, for door weight up to 16 kg (35 lbs.)

Hafele HAWA Clipo 16 H MF Sliding Door Hardware, for door weight up to 16 kg (35 lbs.)

Add to wishlist Add to wishlist

SKU: HA-405.82.118

$203.77
$254.71 $203.77
Active item with the manufacturer but no stock in main warehouse. Possible delay due to warehouse transfer time.
Item typically ships within 7-10 business days . (Minimum order quantity: 1)

Description

Optional soft close
Quick door mounting
No guide rails in the floor
A wood cover panel is not needed

Specifications

  • Number of doors: 2.00
  • Soft closing mechanism: with clip-in door stopper
  • For door thickness: 16 – 19 mm
  • For door width: ≤1,000 mm
  • For door weight: ≤16 kg
  • Running position: Top
  • Number of rollers: 2.00
  • Height adjustment: -1 – 2 mm
  • Running gear guided by: Friction bearing
  • For door material: wood
  • Door width max.: 39 3/8"
  • For door thickness min.: 5/8" and 3/4"
  • Door weight max.: 35 lbs.
  • Height adjustment: +1/16-1/32"
  • Door height min.: 55 1/8"
  • Cabinet version: with thin cabinet top panels
  • Area of application: For thin cabinet top panels
  • For door height: ≤1,400 mm
  • Door stopper: Top clip-in door stopper, for sliding into single running track
  • Material/finish: Housing: PlasticRunning gear: PlasticGuide: PlasticRollers: PlasticAxis: Steel
