Description
Description
Ideal for serving hatches and narrow wooden frame doors
with soft closing mechanism (optional)
Specifications
Specifications
- Number of doors: 1.00
- Soft closing mechanism: with clip-in door stopper
- For door thickness: ≤19 mm
- For door width: ≤1,000 mm
- For door weight: ≤16 kg
- Running position: Top
- Number of rollers: 4.00
- Height adjustment: -1 – 2 mm
- Running gear guided by: Friction bearing
- For door material: aluminum frame
- For door thickness max.: 3/4"
- Door width max.: 39 3/8"
- Door weight max.: 35 lbs.
- Height adjustment: 1/8"
- Door height min.: 55 1/8"
- Cabinet version: with narrow doors
- Area of application: For straight doors
- For door height: ≤1,400 mm
- Door stopper: Top clip-in door stopper, for sliding into running track
- Material/finish: PlasticRollers: PlasticAxis: Steel
