Description
Description
-
Optional soft close mechanism can be inconspicuously integrated into the track so it is not visible and is protected from damage
Rattle-free floor guide
No guide rails in the bottom of the cabinet
Tool-less clip-on hardware allows for quick and easy door mounting
Specifications
Specifications
- Number of doors: 2.00
- Soft closing mechanism: with clip-in door stopper
- For door thickness: 19 – 25 mm
- For door width: ≤1,000 mm
- For door weight: ≤26 kg
- Running position: Top
- Number of rollers: 2.00
- Height adjustment: -2 – 2 mm
- Running gear guided by: Friction bearing
- For door material: wood
- For door thickness max.: 1"
- Door width max.: Max: 3' 3 3/8"
- For door thickness min.: 3/4"
- Door weight max.: 57 lbs.
- Length (inch): 2' 1 19/32"
- Cabinet version: with sliding doors with zero clearance
- Area of application: Sliding doors with guide with zero clearance
- For door height: ≤2,200 mm
- Door stopper: Top clip-in door stopper, for sliding into running track
- Material/finish: Housing: PlasticRunning gear: Zinc alloyGuide: PlasticRollers: PlasticAxis: Steel
What's Included
What's Included
- 4 Running gears
- 4 Housing pieces
- 1 soft stop
- 2 guides
- 4 track stoppers
