Description
Description
-
Optional soft close mechanism can be inconspicuously integrated into the track so it is not visible and is protected from damage
Rattle-free floor guide
No guide rails in the floor
Tool-less slide-on hardware allows for quick and easy door mounting
Specifications
Specifications
- Number of doors: 1.00
- For door thickness: 19 – 25 mm
- For door width: ≤1,000 mm
- For door weight: ≤36 kg
- Number of rollers: 4.00
- Height adjustment: -2 – 2 mm
- For door material: wood
- For door thickness max.: 1"
- For door height (inches): Max: 7' 10 1/2"
- For door width (inches): Max: 39 3/8"
- For door thickness min.: 3/4"
- Door weight max.: 79 lbs
- Weight (pound): Max. door = 79 lbs.
- For door height: ≤2,400 mm
- Material/finish: Rollers: Plastic
- Adjustment facility: Height adjustment: -2 – 2 mm, Height adjustment +/- 2 mm (1/16")
- Set: Set without tracks
- Type of opening: linear
- Number of doors per system max.: 1
What's Included
What's Included
- 2 running gears with housings
- 2 door stoppers
- 1 floor guide
