Description
Description
Excellent running characteristics due to large diameter rollers.
Separate running and guide tracks eliminate door thickness restriction
Specifications
Specifications
- Version: for 2 doors also with soft closing mechanism
- Height adjustment: -2 – 2 mm
- -2 – 2 mm: 16 – 19 mm
- For door weight: ≤55 kg
- Cabinet version: with bottom running door wings
- Area of application: For door weights up to (121 lbs.) 55 kg
- Material/finish: Rollers: PlasticAxis: Steel
- Running position: Bottom
- Number of rollers: 1.00
- Running gear guided by: Ball bearing
- Adjustment facility: Height adjustment: -2 – 2 mm, Height ±2 mm
- Running position: Bottom
- Set: Set without tracks
- Type of opening: linear
- Number of doors per system max.: 2 to 3
What's Included
What's Included
- 6 running gears
- 3 height adjustments
- 3 buffers
- 6 anti-derailment devices (2 for rear doors/2 for front door)
- 6 guides
- 2 door stoppers
