Description

Excellent running characteristics due to large diameter rollers.
Separate running and guide tracks eliminate door thickness restrictions

Specifications

  • Version: for 2 doors also with soft closing mechanism
  • For door thickness: 16 – 19 mm
  • For door weight: ≤55 kg
  • Cabinet version: with bottom running door wings
  • Area of application: For door weights up to (121 lbs.) 55 kg
  • Material/finish: Rollers: PlasticAxis: Steel
  • Running position: Bottom
  • Number of rollers: 1.00
  • Running gear guided by: Ball bearing
  • Adjustment facility: Height ±2 mm
  • Running position: Bottom
  • Set: Set without tracks
  • Type of opening: linear
  • Number of doors per system max.: 2 to 3

What's Included

  • 6 running gears
  • 3 buffers
  • 6 anti-derailment devices (2 for rear doors/4 for front door)
  • 6 guides
  • 2 door stoppers

Fulfill

Hafele Slido F-Line15 55A Sliding Door Hardware, Three Door Set, Without Height Adjustment, For Door Weight 55 kg

Hafele Slido F-Line15 55A Sliding Door Hardware, Three Door Set, Without Height Adjustment, For Door Weight 55 kg

SKU: HA-402.23.001

$380.05
$475.06 $380.05
Active item with the manufacturer but no stock in main warehouse. Possible delay due to warehouse transfer time.
Item typically ships within 7-10 business days . (Minimum order quantity: 1)
Returns: Items may be returned within 14 days. A 25% restocking fee applies.
Full policy →

Description

Excellent running characteristics due to large diameter rollers.
Separate running and guide tracks eliminate door thickness restrictions

Specifications

  • Version: for 2 doors also with soft closing mechanism
  • For door thickness: 16 – 19 mm
  • For door weight: ≤55 kg
  • Cabinet version: with bottom running door wings
  • Area of application: For door weights up to (121 lbs.) 55 kg
  • Material/finish: Rollers: PlasticAxis: Steel
  • Running position: Bottom
  • Number of rollers: 1.00
  • Running gear guided by: Ball bearing
  • Adjustment facility: Height ±2 mm
  • Running position: Bottom
  • Set: Set without tracks
  • Type of opening: linear
  • Number of doors per system max.: 2 to 3

What's Included

  • 6 running gears
  • 3 buffers
  • 6 anti-derailment devices (2 for rear doors/4 for front door)
  • 6 guides
  • 2 door stoppers
