Excellent running characteristics due to large diameter rollers.
Separate running and guide tracks eliminate door thickness restrictions

• Version: for 2 doors also with soft closing mechanism
• Height adjustment: -2 – 2 mm
• For door thickness: 16 – 19 mm
• For door weight: ≤55 kg
• Cabinet version: with bottom running door wings
• Area of application: For door weights up to (121 lbs.) 55 kg
• Material/finish: Rollers: PlasticAxis: Steel
• Running position: Bottom
• Number of rollers: 1.00
• Running gear guided by: Ball bearing
• Adjustment facility: Height adjustment: -2 – 2 mm, Height ±2 mm
• Running position: Bottom
• Set: Set without tracks
• Type of opening: linear
• Number of doors per system max.: 2 to 3

• 4 running gears
• 2 height adjustments
• 2 buffers
• 4 anti-derailment devices (1 for rear door/3 for front door)
• 4 guides
• 1 door stopper
