Sugatsune HG-JH Soft-Close Hinge for Lids
The Sugatsune HG-JH series represents precision-engineered soft-close hinge technology designed specifically for lid applications. These surface-mount hinges feature integrated dampers that prevent lids from slamming shut, ensuring smooth, controlled closing action that protects both the lid and the contents beneath.
Key Features
- Soft-close damper technology keeps lids from slamming shut
- Surface mount design for easy installation
- 115° operating angle with 5° dead angle for optimal functionality
- Operating temperature range: 0~40°C (32~104°F)
- Available in multiple torque ratings to suit different lid weights
- Quality construction with stainless steel and engineered plastic components
- Sold in pairs for complete left and right installation
Applications
Ideal for a wide range of applications including storage boxes, toy chests, bench seats, piano benches, hope chests, and any lid-equipped furniture or storage solution requiring controlled closing action. The soft-close mechanism extends the life of your furniture while providing a premium user experience.
Quality Construction
Each hinge features a robust bracket made from PBT plastic and zinc alloy, a polypropylene cap, and a 304 stainless steel damper assembly. This combination of materials ensures durability, corrosion resistance, and long-lasting performance in residential and commercial environments.
Specifications
Specifications
- Model Number: HG-JH 25
- Torque Rating: 31~51 kgf·cm (27~44 lbs·in) per pair
- Damper Type: A-Type (Counterclockwise)
- Shaft Color: White
- Weight per Pair: 180 grams (0.40 lbs)
- Operating Angle: 115°
- Dead Angle: 5°
- Operating Temperature: 0~40°C (32~104°F)
- Mount Type: Surface Mount
- Bracket Material: PBT Plastic/Zinc Alloy
- Bracket Color: Dark Grey
- Cap Material: Polypropylene
- Damper Material: 304 Stainless Steel
- Damper Finish: Plain
- Packaging: Sold in pairs
What's Included
What's Included
- (1) Pair of HG-JH 25 soft-close hinges (left and right)
- (1) A-Type damper assembly with white shaft
- Mounting hardware and brackets
