ACCESS TO EVERY CORNER.
Even the largest storage space is useless if it's not accessible. That's why this system enables full access to the cabinet contents, transforming every corner into functional space. Installation is unhanded: the frame is mounted to the bottom of the corner cabinet.
Product Benefits
Maximum Access
Unique design allows easy access to 100% of the cabinet
Lock System
This frame only allows desired movement, preventing accidental closing of trays and potential damage to surrounding cabinets.
Integrated Soft And Self Closing
Damping mechanism for smooth and silent operation. No more rattling of pots and pans.
Installation Benefits
Unhanded Installation
No need to worry about right or left handed applications, the VS COR® Flex works both ways!
Installation Template Included For Easy Installation
Measure your opening – then line up with the arrow on the installation template. Excellent results in minutes.
Easy Bottom Mount Installation
Just a few screws secure the frame to the cabi_x0002_net, and the VS COR® Flex is ready for action!
Retrofit Ready
Can be installed in existing cabinetry without removing the countertop.
Specifications
Specifications
- Weight (lbs): 55.9
- Finish: Lava
- Cabinet Opening: 15" (36" Cab. Width)
- Design Group: Scalea
- Number of Bins/Trays/Baskets: 4.0
- Max. Capacity per Bin/Tray/Basket (lbs): 17.5
- Max. Load Capacity for Product (lbs): 70.0
- Cabinet Opening: Face Frame (inches): 15
- Cabinet Opening: Frameless (inches): 15
- Cabinet Width: Face Frame (inches): 36
- Cabinet Width: Frameless (inches): 36
- Min. Installation Height (inches): 22.625
- Min. Installation Depth (inches): 21.625
