Description
Description
The 3040 linear strip light is extra narrow and used for projects when this is a desirable feature. The light output is considered most suitable for "ambient lighting". The strip is equipped with high-quality Samsung® LEDs which come with a lifetime use of over 50,000 hours.
There are some great features to linear light:
- Continuous light line with diffused glow (when using a profile to diffuse diodes)
- Minimalistic design
- Virtually invisible, glare-free light source
- Easy installation
What is the difference between the 3040 LED strip light and 3041 LED strip light?
Both the 3040 and 3041 LED strip light are great for projects that need narrow strip light. The only real difference between the two is that the 3040 has about half the light output and is considered "ambient lighting". So if you need "task lighting" in your application the 3041 LED strip light is a better choice!
Keep in mind the power lead for this
item needs to be ordered separately.
Loox lights and drivers are
"suitable for use within closet storage spaces".
Maximum visual strip length applies
for an imperceptible drop in luminous flux of max. 30%.
3040 Strip Light Output Diagram
3040 Strip Information
Length of Contact Surface (P) = 3 mm (1/8")
Section Length (C) = 25 mm (1")
Max. Strip Length = 3 m (118-1/8")
Loox5 LED Strip Light Connection Video
Specifications
Specifications
- Voltage: 24V
- Dimmable: Yes
- Material: Plastic
- Color: White
- Width: 5 mm (3/16")
- Height: 1.3 mm (1/16")
- Life time L80/B10: > 50000 h
- Energy Efficiency Class: A+
- Degree of Protection: IP20
SKU: SKU: HA-833.76.300
