Description
Description
YOUR STOCKPILE OF ACCESSIBLE STORAGE SPACE.
Every kitchen needs an elegant design. The front opens and shuts easily and silently due to the damping and self closing mechanism of the full extension runners. The frame and the front connections are designed in a high-quality, double powder-coated surface
Product Benefits
PAM:$Optional Power Assisted Movement
Dual direction power mechanism, makes accessing and returning trays super easy. One finger is all it takes to move a fully loaded VS TAL® Pantry!
Optimal Access
Full extension configuration allows for easy access to products stored in the rear as well as the front.
Complete Visibility With One Pull
Open the door and every item is instantly visible.
Save Time
No need to constantly move around items to find the one you need – everything is stored in an easy to access format.
Height Adjustable Trays
Each tray is easily adjusted up or down, allowing you to customize your own VS TAL® Pantry to your tastes and needs.
Combinable
Compatible with the VS ADD® Box and VS ADD® Separator
Integrated Soft And Self Closing
Damping mechanism provides a soft close action of the unit.
Heavy Duty Noise Restricting Roller Slides
Even when loaded to capacity, the VS TAL® Pantry opens and closes effortlessly and quietly.
Synchronised Upper And Lower End Stops
Maintenance free, no more asynchronised rails.
Installation Benefits
EasyFit
Self locking system for tool free installation of frame onto upper and lower glide rails.
3D Front Adjustment
Simple, fast and trouble free adjustment, even after the unit is installed! Up, down, left, right, in and out adjustments are achieved with a simple turn of a screwdriver.
Installation Template Included For Easy Installation
Measure your opening and find the center – then line up with the arrow on the installation template.Excellent results in minutes.
Retrofit Ready
Can be installed in existing cabinetry without removing the countertop.
Three, Four or Five Set Tray Options
For ideal utilization of higher and lower interior cabinet heights.
Specifications
Specifications
- Weight (lbs): 40.1
- Finish: Lava
- Height/Baskets: Height 1, 3 Baskets
- Cabinet Width: 12"
- Design Group: Scalea
- Number of Bins/Trays/Baskets: 3.0
- Max. Capacity per Bin/Tray/Basket (lbs): 35.2
- Max. Load Capacity for Product (lbs): 176.0
- Cabinet Opening: Face Frame (inches): 9
- Cabinet Opening: Frameless (inches): 9
- Cabinet Width: Face Frame (inches): 12
- Cabinet Width: Frameless (inches): 10.5
- Min. Installation Height (inches): 37.5
- Min. Installation Depth (inches): 22.5
